Speedhut 3-3/8″ Dual Oil Temp / Oil Pressure Gauge (R3-DG6-REV)

The Speedhut 3-3/8″ Dual Oil Temp / Oil Pressure Gauge (R3-DG6-REV) offers a convenient and precise way to monitor two crucial aspects of your engine’s performance in a single, easy-to-read unit. This gauge displays both water temperature in Celsius and oil pressure in PSI, providing you with the vital information needed to ensure your engine is running optimally and to identify potential issues before they become serious. With its clear metric readings and included installation hardware, this gauge is a valuable addition to any vehicle.

KEY FEATURES AND BENEFITS:

• Displays both water temperature (50-125°C) and oil pressure (0-100 psi) in one compact 3-3/8″ gauge.
• Provides real-time monitoring of critical engine parameters.
• Features a warning light to alert you to potentially dangerous conditions.
• Designed for easy mounting with the included gauge mounting ring.
• Comes complete with necessary sensors and wiring harnesses for straightforward installation.
• Offers a clean and integrated look compared to installing two separate gauges.

SPECIFICATIONS:

• Gauge Type: Dual Gauge
• Combo Options: Water Temperature and Oil Pressure
• Water Temperature Range: 50-125 °C
• Oil Pressure Range: 0-100 psi
• Units: Metric (Temperature)
• Size: 3 3/8 inch (86mm)
• Hole Size: 3.375 inches (86mm)
• Warning Light: Yes
• Included:
• Pressure Gauge Wiring Harness (3-Wire Cable)
• Pressure Sensor – 100 psi
• Temperature Gauge Wiring Harness (2-Wire Cable)
• Speedhut Temperature Sensor
• 3 ft Power & Lighting Harness – for LED Lit Gauges and Clocks
• Gauge Mounting Ring

HOW TO USE:

1. Mount the Gauge: Secure the 3-3/8″ gauge in a suitable location on your dashboard or instrument panel using the included mounting ring. Ensure the location allows for clear visibility.
2. Install the Pressure Sensor: Locate the appropriate port on your engine for oil pressure measurement and install the included 100 psi pressure sensor.
3. Install the Temperature Sensor: Identify the correct location on your engine’s cooling system (e.g., thermostat housing, coolant passage) and install the provided Speedhut temperature sensor.
4. Connect the Pressure Sensor Wiring: Connect the 3-wire cable from the pressure sensor to the designated terminals on the back of the gauge, following the wiring diagram provided.
5. Connect the Temperature Sensor Wiring: Connect the 2-wire cable from the temperature sensor to the corresponding terminals on the back of the gauge, according to the wiring instructions.
6. Connect the Power and Lighting Harness: Attach the 3 ft power and lighting harness to the appropriate power, ground, and lighting sources in your vehicle, and connect it to the gauge.
7. Verify Connections: Double-check all wiring connections to ensure they are secure and correct.
8. Test the Gauge: Start your vehicle and observe the gauge readings to confirm that the water temperature and oil pressure are being displayed accurately. Check that the warning light functions as expected.

BENEFITS OF USING THE SPEEDHUT 3-3/8″ DUAL OIL TEMP / OIL PRESSURE GAUGE (R3-DG6-REV):

• Space Saving: Combines two essential readings into a single gauge, reducing clutter on your dashboard.
• Enhanced Monitoring: Provides continuous, real-time data on your engine’s water temperature and oil pressure, allowing for early detection of potential problems.
• Clear Metric Readings: Displays water temperature in Celsius, a common and often preferred unit of measurement.
• Easy Installation: Comes with all necessary sensors and wiring, simplifying the installation process.
• Early Warning System: The integrated warning light can alert you to overheating or low oil pressure conditions, potentially preventing engine damage.

FEATURES:

• Simultaneous display of water temperature and oil pressure.
• Metric temperature scale (Celsius).
• Dedicated 100 psi pressure sensor included.
• Specific Speedhut temperature sensor provided.
• Integrated warning light for critical conditions.
• Straightforward wiring harness system.
• Secure spin-lock mounting mechanism.
• Illuminated display for easy viewing in all lighting conditions.
