AIMS Power 5000 Watt 12V DC to 240V AC Inverter (PWRINV5K24012W)

AIMS Power 5000W 12V DC to 240V AC Power Inverter (PWRINV5K24012W) is designed to convert DC (direct current) power stored in batteries into AC (alternating current) electricity. With continuous output power and surge capabilities, this inverter is perfect for powering tools, appliances, or equipment that require 240V AC. It is ideal for off-grid use, including backup power for homes, cabins, RVs, boats, and larger solar systems. Unlike other models, this inverter exclusively supports 240V AC and will not provide 120V AC output—making it a solid choice for applications that need higher voltage.

The unit is designed for mobile businesses, making it especially valuable for running small offices, work trucks, construction vehicles, or lawn maintenance equipment. Notably, it operates directly from 12V power systems, eliminating the need for costly system upgrades for vehicles or fleets.

Key Features:

• Max Continuous Power: 5000 watts
• Surge Power: 10,000 watts (peak)
• Output Voltage: 240V AC (single-phase, no 120V AC output)
• Input Voltage: 12V DC (operating voltage range: 10V to 15V)
• Output Frequency: 60 Hz ± 0.5 Hz
• AC Output Sockets: Dual 240V outlets
• Protection: Overload, over-temperature, and short-circuit protection
• Monitoring: Volt meter and amp meter for battery and current usage monitoring
• Cooling: Single thermally controlled cooling fan
• Battery Voltage Alarms: Low voltage alarm at 10.5V and shutdown at 10.0V
• Dimensions: 16.92″ L x 7.95″ W x 6.1″ H
• Weight: 16.72 lbs (unit), 20 lbs (boxed)
• Warranty: 1-year parts and labor, free tech support
• Mounting: Pre-slotted mounting plate for easy installation
• Cooling System: Aluminum case for optimal cooling

Specifications:

• Continuous Output Power: 5000W
• Surge Power: 10,000W (Peak)
• Operating Voltage: 12V DC (range 10-15V DC)
• Output Voltage: 240V AC (single-phase)
• Output Frequency: 60Hz ±0.5Hz
• Battery Low Voltage Alarm: 10.5V ± 0.5V
• Battery Low Voltage Shutdown: 10V ± 0.5V
• Operating Temperature: No load minimum -15°C, full load max 55°C (automatic shutdown)
• AC Output Socket Type: Dual 240V AC
• Protection Features: Low voltage, over-voltage, overload, short circuit, and thermal protection
• Pre-wired: Remote on/off switch, pre-slotted mounting plate
• Included Components: Instruction manual, free tech support
