AIMS Power 4000W Pure Sine Low Frequency Inverter Charger (PICOGLF4012120240VS)

AIMS Power 4000W Pure Sine Low-Frequency Inverter Charger is a powerful and reliable solution for residential and industrial applications that require high-quality, consistent power. The inverter’s pure sine wave technology ensures clean, stable power, ideal for sensitive equipment. With a split-phase output, it is versatile enough to work with various electrical systems. The built-in multi-stage charger is compatible with lithium LiFePO4, AGM, gel, and lead batteries. Other notable features include a remote panel for easy monitoring, a battery priority selector, and an automatic transfer switch. Designed for durability, this unit is marine-coated for extra protection in harsh environments.

Key Features & Specifications:

• Continuous Output Power: 4000 Watts
• Surge Rating: 12,000 Watts (for 20 Seconds)
• Output Voltage: 120/240 VAC – Split Phase 60Hz
• Output Waveform: Pure Sine Wave / Same as Input (Bypass Mode)
• Nominal Efficiency: >88% (Peak)
• Line Mode Efficiency: >95%
• Output Frequency: 60Hz ± 0.3Hz
• Transfer Time: 10ms (Max)
• Total Harmonic Distortion (THD): < 10% DC
• Operating Temperature Range: 14°F to 122°F (-10°C to 50°C)

Input Specifications:

• Nominal Input Voltage: 12.0V DC
• Minimum Start Voltage: 10.0V DC
• Low Battery Alarm: 10.5V – 11.0V
• Low Battery Trip: 10.0V – 10.5V
• High Voltage Alarm: 16.0V DC
• Battery Voltage Restart: 15.5V DC
• Idle Consumption: 50W (Power Saver Mode: 21W)

Charger Specifications:

• Charger Rate: 115A
• Charge Protection Shutdown: 15.7V
• Selectable Charge Setting: Based on battery type
• Adjustable Charge Current: Off-20%-100%
• Four-Stage Smart Charger

Transfer Switch Specifications:

• 40 Amp Automatic Transfer Switch
• Transfer Time: 10ms (Max)

Dimensions:

• Unit Weight: 75 lbs
• Unit Size (L x W x H): 31.5″ x 8.75″ x 7.25″
• Shipping Weight: 87 lbs
• Shipping Size (L x W x H): 35.5″ x 14.5″ x 13.5″
