AIMS Power 4000 Watt Pure Sine Inverter Charger (PICOGLF40W48V240VS)

AIMS Power PICOGLF40W48V240VS 4000 Watt Pure Sine Inverter Charger is a reliable solution for backup and off-grid power applications. With a built-in transfer switch and a multi-stage smart charger, this inverter delivers efficient power conversion. Designed for heavy-duty use, it provides a surge capacity of 12,000 watts, making it perfect for running high-demand appliances and tools. The marine-coated design protects against humidity and dust, making it ideal for RVs, boats, and mobile applications. Equipped with dual thermally-controlled fans and over-temperature protection, this inverter ensures safe operation under extreme conditions. Additional features like a battery priority selector and remote panel availability give users complete control over their power needs.

Features:

• 4000-watt continuous power with 12,000-watt surge capacity.
• Pure sine wave output supports sensitive electronics.
• Built-in 50A automatic transfer switch.
• Multi-stage smart charger with adjustable settings.
• Marine-coated circuit boards for dust and moisture resistance.
• Battery priority selector for customized power management.
• Dual thermally controlled cooling fans for optimal performance.
• Remote panel available for convenient monitoring.

Benefits:

• Reliable off-grid and backup power for homes, RVs, and boats.
• Seamless transition with a fast 10ms transfer time.
• Protects and extends battery life with smart charging.
• Withstands extreme conditions with thermal protection.
• Provides clean power for sensitive electronics and appliances.

Technical Specifications:

• Model: PICOGLF40W48V240VS
• Continuous Output Power: 4000 Watts
• Surge Rating: 12000 Watts (20 Seconds)
• Output Voltage: 110/120/220/240 Vac
• Output Waveform: Pure Sine (Bypass Mode)
• Nominal Efficiency: >88% (Peak)
• Line Mode Efficiency: >95%
• Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
• Typical Transfer Time: 10ms (Max)
• Total Harmonic Distortion (THD): <10% DC
• Nominal Input Voltage: 48.0 Vdc
• Minimum Start Voltage: 44.0 Vdc
• Low Battery Alarm: 42 Vdc – 44.0 Vdc
• Idle Consumption: 1.67 Amps DC
• Charger Rate: 40A
• Over Charge Protection Shutdown: 62.8V
• Dimensions: 23.5 x 8.74 x 7.10 inches
• Unit Weight: 64 lbs.
• Shipping Dimensions: 30.5 x 14.25 x 13.75 inches
• Shipping Weight: 75 lbs.
• Automatic Transfer Switch: 50 Amp @ 120Vac or 30 Amp @ 240Vac
